2Input 1Output Waterproof Plastic Electrical Combiner Box

Ask Lasest Price
Brand Name :	SUNTREE
Model Number :	SHLX-PV2/1
Supply Ability :	5000 Piece/Pieces per Month
Price :	Competitive prices

Add to Cart

Product Details
Company Profile

2Input 1Output Waterproof Plastic Electrical Combiner Box

New Professional Outdoor Electrical DC Combiner Box IP65 Waterproof Plastic Boxes 2 Input 1 Output

Product Description

SHLX-PV2/1 combiner box is suitable for inverter (MAX input voltage DC550V/DC1000V,2PV input channel, 1 output channel, single MPPT inverter). Box body is made of PVC engineering materials,with test for fire retardant, Temperture rise,anti impact, anti ultraviolet, and other testing. IP65 protection grade.

Design and configuration strictly accordance with the "Technical specification for photo-voltaic junction equipment'' CGC/GF 037:2014.

Provide users with a safe, brief, beautiful and applicable photo-voltaic system products.

Product Parameters

Name	SHLX-PV2/1		SHLX-PV12/1
System maximum dc voltage	550	1000
Maximum input current for each string	15A		15A
Maximum input strings	2		4
Maximum output switch current	20A/32A		50A/63A
Number of inverter MPPT	1		1
Number of Output strings	1		1
Category of test	‖ grade protection		‖ grade protection
Nominal discharge current	20ka		20ka
Maximum discharge current	40ka		40ka
Voltage protection level	2.8kv	3.8kv
Maximum continuous operating voltage Uc	630V	1050A
Poles	2P	3P
Structure characteristic	Plug-push module		Plug-push module
Protection grade	IP65		IP65
Output switch	DC isolation switch(standard)/DC circuit		DC isolation switch(standard)/DC circuit
DC MC4/DC FUSE/DC Surge Protector	Standard		Standard
Monitoring module/Preventing diode	Optional		Optional
Installation method	Wall mounting type		Wall mounting type
Operating Temperature	-25℃--+55℃		-25℃--+55℃
Elevation of temperature	2km		2km
Permissible relative humidity	0-95%, no condensation		0-95%, no condensation

Product Details Show

2Input 1Output Waterproof Plastic Electrical Combiner Box

Our Advantages

♦High reliability
With DC FUSE
With DC Surge Protection Device
With DC circuit breaker or DC load isolation switch.

♦Strong adaptability
IP65 desigh,waterproof,anti dust and anti ularaviolet.
Strict test for high and low temperature,used widely/
The simple installation, the simplified system wiring, the convenient wiring.
The box body is made of cold rolled steel and other metal materials.

♦Flexible configuration
Used for single crystal silicon solar modules, polycrystalline silicon solar modules, thin film solar modules. Current rating of the photovoltaic fuse, cicuit breaker, load isolation switch is modified.

Recommend Products

Company Profile

FAQ

Q: How can i trust you and your company ?

A: Suntree is a group company, we have 6 subcompanies. Have cooperation with LS, EKF the world-class companies. Our company over 500 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.

Q: How long is your products warranty ?

A: The warranty period of our products is 2 Years.

Q: How about inspection?

A: We have the whole inspection system from raw material to end products include Transient test, delay test,mechanical life test and so on.

Q: What is the service offered by company?

A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement.

We also have the sales team to offer good service from pre-sale to after-sale.
